| BR16GM-S,
BR160GM-S,
BR160SM-S
standard version for alarming and digital signal monitoring. You can connect to
digital inputs motion detector, smoke/temperature detector, siren, thermostat,
level sensor etc.). |


BR16GM-S
/ BR16GM-S-B GSM
850/900/1800/1900 with GSM antena, without or with PACTEC JM33 box
182
EUR / 189 EUR discount 20%
for industrial
and home applications

|

BR160GM-S
/ BR160GM-S-B GSM
850/900/1800/1900 with GSM antena, without or with DIN-rail enclosure (DIN-Rail
products)
190 EUR / 199 EUR discount 20%
 BR160GM-S-IP56 GSM
850/900/1800/1900 with GSM antena, with IP56 enclosure
200 EUR discount
20%
for industrial and home applications

|
BR160SM-S
/ BR160SM-S-B GSM
900/1800/1900 with GSM antena, without or with DIN-rail enclosure (DIN-Rail
products)
130 EUR / 139 EUR discount 20% BR161SM-S
/ BR161SM-S-B GSM
850/900/1800/1900 with GSM antena, without or with DIN-rail enclosure (DIN-Rail
products)
136 EUR / 145 EUR discount 20% for
home application

|
BR16GM-2A,
BR160GM-2A, BR160SM-2A
or BR16GM-4A,
BR160GM-4A,
BR160SM-4A
- analog version for slow analog and digital signal monitoring. You can connect
to 2 or 4 analog inputs external sensors with 0-5V/0-10V/0-20mA/4-20mA outputs
(humidity sensor, anemometer, level sensor, pressure sensor etc.). Note: BR16GM-2A
and BR16GM-4A required analog adapter #4A, who consist resistor dividers and protection
circuits for analog signal. |

BR16GM-2A
BR16GM-4A
GSM 850/900/1800/1900 with GSM antena, with adapter #4A
189
EUR discount 20%
for industrial and home
applications

|
|
BR160SM-2A BR160SM-4A
/ BR160SM-2A-B
BR160SM-4A-B GSM
900/1800/1900 with GSM antena, without or with DIN-rail enclosure (DIN-Rail
products)
130 EUR / 139 EUR discount 20% BR161SM-2A BR161SM-4A
/ BR161SM-2A-B
BR161SM-4A-B GSM
850/900/1800/1900 with GSM antena, without or with DIN-rail enclosure (DIN-Rail
products)
136 EUR / 145 EUR discount 20% for
home application

|
| | -2A |
-4A | | analog
event inputs | 2 |
4 | | digital
event inputs | 4 |
6 | | outgoing
numbers filter for alarm SMS | yes |
no | | digital
signal filtere | yes |
no | | total
digital event inputs with analog inputs | 6 |
10 | | module-module
communication | ++ |
+ | |
| |


BR16GM-2SMT
/ BR16GM-2SMT-B
GSM 850/900/1800/1900 with GSM antena, without or with PACTEC JM33
box
182 EUR / 189 EUR discount 20%
for
industrial and home applications

|

BR160GM-2SMT
/ BR160GM-2SMT-B
GSM 850/900/1800/1900 with GSM antena, without or with DIN-rail
enclosure (DIN-Rail products)
190 EUR / 199 EUR discount
20%  BR160GM-2SMT-IP56
GSM 850/900/1800/1900 with GSM antena, with IP56 enclosure
200 EUR discount 20%
for industrial
and home applications

|
BR160SM-2SMT
/ BR160SM-2SMT-B
GSM 900/1800/1900 with GSM antena, without or with DIN-rail enclosure (DIN-Rail
products)
130 EUR / 139 EUR discount 20% BR161SM-2SMT
/ BR161SM-2SMT-B
GSM 850/900/1800/1900 with GSM antena, without or with DIN-rail
enclosure (DIN-Rail products)
136 EUR / 145 EUR discount
20% for home application

|
BR16GM-Gate,
BR160GM-Gate,
BR160SM-Gate-
Gate opening module. Access control and supervision of gate entries. Gate open
with call from cell phone. Abonent numbers in SIM phone book. Add/Delete abonent
number with SMS. |

BR16GM-Gate
/ BR16GM-Gate-B GSM
850/900/1800/1900 with GSM antena, without or with PACTEC JM33 box
182
EUR / 189 EUR discount 20%
for industrial
and home applications

|

BR160GM-Gate
/ BR160GM-Gate-B
GSM 850/900/1800/1900 with GSM antena, without or with DIN-rail
enclosure (DIN-Rail products)
190 EUR / 199 EUR discount
20%
 BR160GM-Gate
GSM 850/900/1800/1900 with
GSM antena, with IP56 enclosure
200 EUR discount
20% for industrial and home applications

|
BR160SM-Gate
/ BR160SM-Gate-B GSM
900/1800/1900 with GSM antena, without or with DIN-rail enclosure (DIN-Rail
products)
130 EUR / 139 EUR discount 20% BR161SM-Gate
/ BR161SM-Gate-B GSM
850/900/1800/1900 with GSM antena, without or with DIN-rail enclosure (DIN-Rail
products)
136 EUR / 145 EUR discount 20% for
home application

|
BR16GM-S-GPS
è BR160GM-S-GPS
- GPS by SMS. You can receive SMS, periodic SMS and alarm SMS
with object position. Compatibel with Google Earth & Google Maps. |


BR16GM-S-GPS
/ BR16GM-S-GPS-B
GSM 850/900/1800/1900 with GSM antena, with GPS antena, without
or with PACTEC JM33 box
212 EUR / 219 EUR discount
20%
for industrial and home applications

|
BR160GM-S-GPS
/ BR160GM-S-GPS-B
GSM 850/900/1800/1900 with GSM antena, with GPS antena, mit oder ohne
DIN-Rail enclosure (DIN-Rail products)
220 EUR / 229 EUR discount
20%
for industrial and home applications

|
BR160GM-S-GPS-IP56
GSM 850/900/1800/1900 with GSM antena, with GPS antena, with IP56
enclosure
230 EUR discount 20%
for
industrial and home applications
|
BR128GM
GPRS-FTP DATA-LOGGER (GSM 850/900/1800/1900) with internal GSM modem
with integrated SIM card reader. Support temperature, analog and digital signal
monitoring. 4 temperature inputs (with adapte #Pt1000, 4 analog inputs (with adapter
#4A), 7 digital inputs, 5 outputs. You can send SMS and turn on/off remote
equipment. You can receive SMS messages at occurrence of the certain events -
operation of entrance sensors. You can send SMS messages for management of the
various equipment (conditioner, heating equipment, pump). Data Logger function:
csv-files on FTP server. Internal and external control. Module-Module
communication.
|
BR128GM
GSM 850/900/1800/1900 with GSM antena, RS232 cable
265 EUR discount
10%
for industrial and home applications

|
BR128GM-B
GSM 850/900/1800/1900 with GSM antena, with box PACTEC JM33, RS232
cable
272 EUR discount 10%
for
industrial and home applications

|
|
BR128GM-4A
- analog version for slow analog and digital signal monitoring. You can connect
to 4 analog inputs external devices with 0-5V/0-10V/0-20mA/4-20mA outputs (humidity
sensor, anemometer, level sensor, pressure sensor etc.). You can set two minimum
and two maximum level with timeout filter for for analog inputs.
BR128GM-4A/Pt1000 - temperature version for 4 temperature, 4
analog and 7 digital signal monitoring. You can connect to 4 Pt1000 (Pt100) temperature
sensors. You can set two minimum and two maximum level with timeout filter for
temperature and for analog inputs. BR128GM-SHT
- for temperature and humidity monitoring. For Sensirion humidity
and temperature sensor SHT1x, SHT7x SHT humidity/temperature sensor.
Note: BR128GM for analog signal or for Pt1000 temperature sensor connection
required analog adapter #4A or analog/temperature adapter #4Pt1000/4A,
who consist resistor dividers and protection circuits for analog signal.
|

BR128GM-4A
GSM 850/900/1800/1900 with GSM antena, with adapter #4A, RS232 cable
272
EUR discount 10%
for industrial and home
applications

|
BR128GM-4A/Pt1000
GSM 850/900/1800/1900 with GSM antena, with adapter #Pt1000/4A, RS232
cable
310 EUR discount 10%
for
industrial and home applications

|
BR128GM-SHT
GSM 850/900/1800/1900 with GSM antena, with adapter #4A, RS232 cable
272
EUR discount 10% 310 EUR (with SHT11 sensor) discount
10%
for industrial and home applications

|
BieneRemote128GM-WS
- SMS/GPRS METEO monitoring for ULTIMETER
U100 Weather Station. You can receive weather information from Weather
Station with SMS. BR128GM-WS has GPRS Data-Logger function. |

BR128GM-WS
GSM 850/900/1800/1900 with GSM antena, RS232 cables
272 EUR discount
10%
for industrial and home applications

|
BR128GM-WS-B GSM
850/900/1800/1900 with GSM antena, with box PACTEC JM33, RS232 cables
279
EUR discount 10%
for industrial and home
applications

|
BR128GM-WS
GSM 850/900/1800/1900 with GSM antena, with analog adapter #4A, RS232
cables
279 EUR discount 10%
for
industrial and home applications

| BR1281GM-4A/Pt1000,
BR1283GM-4A/Pt1000
- for 4 temperature, 4 analog and 6digital signal monitoring. You can connect
to 4 Pt1000 (Pt100) temperature sensors. You can set two minimum and two maximum
level with timeout filter for temperature and for analog inputs. GPRS/FTP data-logger. Functionally
= BR128GM-4A/Pt1000. BR1281GM-4A/Pt1000
- with power supply on board |
BR1281GM-4A/4Pt1000
GSM 850/900/1800/1900 with power supply on board with GSM antena,
RS232 cable
330 EUR discount 10%
for
industrial and home applications
|
BR1283GM-4A/4Pt1000
GSM 850/900/1800/1900 with GSM antena, RS232 cable
310 EUR discount
10%
for
industrial and home applications
| | BR1280GM
(GSM 850/900/1800/1900) with internal GSM modem with integrated SIM card
reader. Support temperature, analog and digital signal monitoring. 3/1 temperature
inputs (with Smartec SMT160-30 or Smartec Temperature Probe assenbly), 8analog
inputs (0/5V,0-10V,0-20mA,3-20mA), 10/12 digital inputs, 8 outputs. Real Time
Clock with battery on board. You can send SMS and turn on/off remote equipment.
You can receive SMS messages at occurrence of the certain events - operation of
entrance sensors. You can send SMS messages for management of the various equipment
(conditioner, heating equipment, pump). Data Logger function: csv-files on FTP
server. Internal and external control. Module-Module communication.
|  BR1280GM
/ BR1280GM-B GSM
850/900/1800/1900 with GSM antena, without / with DIN-Rail enclosure, RS232
cables
330 EUR / 345 EUR discount 10%
for
industrial and home applications

|
Optional
- MODBUS, RS485 / RS232 support
software development from 400
EUR
|
| Accessories
for BieneRemote module
| SmartecTemperature
Sensors |  Temperature
Probe bSMT16030 Sensor SMT160-30 TO18 or Sensor SMT160-30 TO92,
Cable: 5 m. shielded temperature range -45 to +130 °C.
|
Smartec
Temperature Sensor SMT160-30 temperature range -45 to +130 °C. | | Stabilised
Power Supply (compatibel for all BieneRemote modules) |
DR-4512
Mean Well 12vdc AC/DC Switching Power Supply, Single Output, DIN Rail 85
~ 264Vac / Stabilized 12V 3.5A 42W 93 x 78 x 67mm, DIN Rail |
EA10302
Switching Power Supply 90-264Vac Stabilized 12V, 2,5A Edacpower 98x45x31mm;
220g
| Others
|
Edge
Connector 31 way (made in USA) RS catalog 403-796
10 EUR for 5
pcs

|
DB19F,
DB19M D-sub connector with metalic cover 15 EUR for 9 pcs complete set

|
| | |
